Scope of Application
 ◎Medicine granulating and coating
Granulating: granule of tablet, quick solved drink, granule used for capsule Coating: granule, pill protection layer , formulated color , slow release, film,coating for intestines solving
◎Foodstuff granulating and coating
Sugar , cof fee, cocoa powder , cream, powder syrup, amino acid, avoring,puffed foo
◎Granulating for pesticide,plgment,dyestuff
◎Drying for powder,granule,block raw materials
Characteristics
◎Because of powder granulating, the uidity can be improved and the powder dust can be reduced.
◎Because of powder granulating, the solubility is improved
◎The procedures of mixing, granulating and drying can be nished in one step(granulating through one step)
◎Because the atomizer for adhesive adapts multi- uid spray lance, the particle is uniform and the percent of pass of nished products is raised greatly .
◎There is no dead corner in equipment. It is quick and convenient to feeding and discharge.
◎The equipment is clean through washing .
Technical Parameter
| Specification |
3 |
5 |
15 |
30 |
45 |
60 |
90 |
120 |
150 |
200 |
300 |
500 |
| Volume(L) |
12 |
22 |
45 |
100 |
155 |
220 |
300 |
420 |
530 |
660 |
1000 |
1500 |
| Amount to be treated(kg/per time) |
1.5/4.5 |
4/6 |
10/20 |
15/45 |
25/65 |
40/80 |
60/120 |
80/160 |
90/200 |
100/300 |
150/450 |
300/300 |
| Power of fan(kw) |
2.2 |
3 |
4 |
5.5 |
7.5 |
11 |
15 |
18.5 |
18.5 |
22 |
30 |
37 |
| Consume of steam 0.4MPa(kg/h) |
12 |
23 |
42 |
70 |
99 |
141 |
169 |
211 |
251 |
282 |
366 |
451 |
| Consume of compressed air m3/min |
0.3 |
1.3 |
0.3 |
0.4 |
0.4 |
0.6 |
0.6 |
0.9 |
0.9 |
0.9 |
1.3 |
1.5 |
| Noise,db(A) |
（fan is installedseparately）≤75 |
| Overall dimension(m) |
1.0x
0.55x1.8 |
1.2x
0.6x2.1 |
1.25x
0.9x2.1 |
1.6x
0.9x2.3 |
1.65x
1.1x2.4 |
1.85x
1.25x3 |
1.85x
1.25x3 |
2.2x
1.65x3.1 |
2.27x
1.72x3.1 |
2.34x
1.9x3.5 |
2.8x
1.9x3.8 |
3x
2.55x4.2 |
Note:Model FG can not be equipped with granulating part.
|
